Currie tech IZIP - Fuses

47

AllCurrieTechnologies®HybridElectricBicyclesareequipped
with fuses. The fuse may be located, depending on the model of
bike, in the following locations
• CXSeries(40Aglasstypefuse)-Onthebatterypack,
externally accessible
• RMBSeries(40Aglasstypefuse)-Onthebacksideofthe
battery pack, externally accessible
• STBSeries(24V,40Aglasstypefuse)-Insidethebattery,
must open the battery pack to access
• STBSeries2011+(24V,40Aglasstypefuse)-Onthe
battery pack, externally accessible
• STBSeries(36V,40Aglasstypefuse)-Onthebattery
pack, externally accessible
• EnlightenedSeries(Li-Ion,30Abladetypefuse&5Ablade
type fuse) - inside the bottom end of the downtube, remove
downtube cap to access
Intheeventofanoverloadthefusewillpopandneedtobe
replaced.Inthisinstancereplaceonlywithanapprovedpartfrom
Currie Technologies®

!
RMBBicycles(2007,2008)CXBicycles
STBBicycles(24V)
STBBicycles(24V)2011
STBBicycles(36V)
EnlightenedSeries(Li-Ion)
