Currie tech IZIP - Front Wheel - Bolt-On

66



AxleNut
Axle
Hub
ConeNut
ForkDropOut
Retaining
Washer
Step
Retaining
Washer
!

1. Makesurethebrakesarelooseenoughtoallowthewheelto
pass through the brake pads easily.
2. Placewheelintoforkdropouts.
3. Installretainingwasherswithraisedlippointedtowardsthe
fork,andinsertintothesmallholeoftheforkblade.NOTE:
Somebikesmayhavestepretainingwashersinplaceofthe
retainingwasher(shownindottedbox).Ifso,installthestep
retaining washer, raised portion sliding in to the fork dropouts.
4. Installaxlenutandtighten.Makesurethewheeliscentered
between the fork blades.
5. Spinthewheeltomakesurethatitiscenteredandclearsthe
brake shoes. Tighten the brakes if necessary.
