Currie tech IZIP - Front Derailleur

79

Shiftbothshifterstothesmallestnumberindicatedandplacethe
chainonthecorrespondingcogandchainwheel.Disconnectthefront
derailleur cable from the cable anchor bolt. Check the position of the front
derailleur; it should be parallel with the outer chainwheel and clear the
largestchainwheelby1-3mmwhenfullyengaged.
With the chain on the smallest chainwheel in front and the largest cog
inback,adjusttheLowlimitscrewsothechainiscenteredinthefront
derailleurcage.Reconnectthecable,pullanyslackout,andtightenthe
anchorboltsecurely.Shiftthefrontshiftertothelargestchainwheel.
Ifthechaindoesnotgoontothelargestchainwheel,turnthehighlimit
screwin1/4turnincrementscounter-clockwiseuntilthechainengages
thelargestchainwheel.Ifthechainfallsoffthelargestchainwheel,and
intothepedals,youwillneedtoturntheHighlimitscrewin1/4turn
increments clockwise until the chain no longer falls off.
Shiftthrougheverygear,usingthebarreladjusterstofinetunethe
cable tension. The barrel adjuster for the front derailleur is located on
the front shifter where the cable comes out of the shifter. Clockwise will
loosen the cable tension and direct the chain closer to the frame while
counter-clockwise will tighten the cable tension and direct the chain
away from the frame.










LowAdjustingScrew
CableAnchorBolt
DerailleurCage
HighAdjusting
Screw
Chainguide
clearance of
1-3mm
!


!
Shifttherearshiftertothegearoneandplacethechainonthelargest
cog.AdjusttheLowlimitscrewinquarterturnincrementsuntiltheguide
pulleyandthelargestcogarealignedvertically.Again,shiftthrough
each gear several times, checking that each gear is achieved smoothly.
Itmaytakeseveralattemptsbeforetherearderailleurandcableis
adjusted properly.
