Currie tech IZIP - Handlebar and Stem Installation

56











1. Removetheprotectiveshippingcapfromthestemwedge.
2. RemovetheStemPlugfromthestem.LoosentheStemBoltwitha
6mmallenwrenchor13mmboxwrench.
3. Insertthestemintotheheadtubeofthebicycle.Ensurethatthe
MinimumInsertionLineisbelowthetopnutoftheheadset.
4. Alignthestemandhandlebarsoitisinlinewiththefrontwheel.
5. TightentheStemBoltwiththe6mmallenwrench.ReinserttheStem
Plugintothestem.
6. Checktheheadsetforsmoothrotationandthatthetopnutissecured
tightly.
7. Loosenthe6mmBinderBoltandrotatethehandlebarsotheleversare
ata45degreeanglebelowthehandlebar.
8. RetightentheBinderBolttoensurethehandlebardoesnotrotatein
the stem.


!
MinimumInsertion
Mark
StemBolt
Head Tube
Binder Bolt
TopNut
Wedge
Somemodelsofbicyclesmaybeequippedwithastemthathas
anadjustableangle.Inadditiontothenormalassembly,thesestemswill
require angling the stem to the desired position, and securely tightening
the6mmAllenboltlocatedunderneaththestem.

