Currie tech IZIP - Disc Brakes - Avid BB7

76

1. Checkthetightnessofthesixdiscmountingboltsholdingthebrakerotor
ontothewheel.Ifyouneedtoremovethesebolts,besuretousathread-
locking compound when re-installing them.
2. Makesurethetwoboltssecuringthecaliperadaptorbrackettothefork
are tight.
3. Installthewheel,makingsurethebrakerotorfitsintotheslotinthe
caliper.
4. Turnthetwopadadjustmentknobscounter-clockwisefully.
AdaptorBracket
Bolts

2
BrakeRotor
(attached to wheel)
3 4
1


Innerpadadjustingknob
Outerpadadjustingknob


