CVC TECHNOLOGIES, INC. CVC 400 OPERATION MANUAL
No. Nomenclature No. Nomenclature
1 Height adj. knob for top hold-down bar 10 Top Hold-down bar Assembly
2 Emergency Stop Button 11 Separating screw device (optional)
3 Labeling Roller 12 Swiveling caster
4 Tension arm 13 Rewind spool disk
5 HHT control panel 14 Control box
6 Label roll disk 15 Conveyor
7 Labeling head A 16 Label Peel Blade
8 Labeling head B 17 Alignment Mechanism
9 Main power switch
Labeling Head Layout
Fig 6.1-3
6 - 3
