7.2.4 C8-R, C10, C11: DC Motor Driver for Label Roller, Product Separator Wheel, Conveyor
C12-PP: DC Motor Driver for Press & Push Attachment (Optional)
Item Function Item Function
AC+ AC 110V+ STOP Brake/Stop
AC- AC110V - GND Brake/Stop
M+ DC Motor output, +(plus), voltage: 0~130V F1 3A 20mm fuse
M - DC Motor output, -(minus), voltage: 0~130V MV Max voltage: Max. voltage limitation
VIN Control Voltage 0~4.65V FV Torque adjustment
GND Control Voltage 0~4.65V *CL, OL *Circuit limit, Over current limit (spare use)
M+
M-
M+ YEL
M- (WHT)
AC+ (BLK)
AC- (RED)
AC+
AC -
F1
MV
GND (PUR)
Power supply
indicator ○
3
GND (ORG)
VIN (BRN)
STOP
(
GRN
)
5V
VIN
STOP
GND
U7
Power supply
indicator ○
1
Power supply
indicator ○
2
MV
U7
FV
CL
OL
