Touching Materials opens the Materials page, where the default characteristics for each
material can be changed, or a new material can be configured.
To be allowed to access the Materials page, a level 2 password is required.
The Materials page displays:
• Material: Selected material (here Steel).
• K Factor for the material (by default DIN6935).
• Default sigma: Default sigma for the material (here 45).
• Default thickness for the material.
• Thickness min/max: Determines the maximum and minimum accepted thickness
for the selected material.
• Three predefined default materials are available (steel, stainless steel, aluminium),
but others can be added
To add a material:
1. Touch and write the name of the new material.
2. Enter the new material’s characteristics.
To remove a material:
1. Select the material you want remove.
2. Touch and confirm the suppression of the material.
