The machine can be equipped with more than a pair of tools. The function Station manage the the tools configuration
and the position of each game of tools in the machine.
SETTING INSTRUCTIONS:
1. Press on the top center of the Bend Numerical Page.
2. Table:
• Number of the station
• Punch
• Die
• Position from origin
• Length of the tools
3. Commands:
• Add station
• Remove station
• Move selected station into another position
• Move selected station to the left or to the right from the actual position
4. Fill the table data for each station by choosing the station tools and , set the
position from the origin and the size of the punch and die tools .
