In this mode, the operator can define each step (length and angle) with the origin of the
previous step through axes U and W.
SETTING INSTRUCTIONS:
1. Select the reference step through the Touch profile or the L-Alpha
The line will have a yellow ball in the middle.
2. Press this button to access the U-W mode .
The reference line will automatically be in the middle of the Touch profile screen
3. Enter the values in U and in W
i.e.:
The step length will be automatically calculated i.e.:
5. Commands:
• Add bend
• Remove bend
• Move selected bend into another position
