In the Bend 2D page, the operator must determine the back gauge and part position for
each bend, and if necessary Extra Bending Parameters.
1. Start the hydraulic pump motor (by pressing this button if available. It turns
red when the motor is running).
2. Press to index the machine
3. Press the button to position the machine according to the data that were just
entered.
4. When the machine is ready to bend, a button is displayed.
5. If you want to repeat the same step in order to apply all the necessary corrections
to it, switch to the Semi-Automatic mode.
6. Press the foot switch to execute the bend.
