In this mode, the operator can define each step (length or angle) of a profile on a table.
On the left side of the screen the L-Alpha mode is accessible at any time.
SETTING INSTRUCTIONS:
1. Table:
• N Bend number
• Flange Length (exterior)
• Bend angle
• More parameter for step
2. Commands:
• Add bend
• Remove bend
• Move selected bend into another position
3. If a bend needs special parameters (large radius, special tool), press in the more
field of the corresponding sequence.
A special punch or /and die means there must be an additional working station.
4. Once all the segments and angles are adjusted, press this button to access
Bend Sequencing.
