User Manual Visipac & VisiTouch Series
VisiPac & VisiTouch series User Manual
MAR.
2021
V1.0
18/69
This function allows the calibration of the touch screen.
SETTING INSTRUCTIONS:
Simply follow the instructions on the page to calibrate the touchscreen.
Use your finger or the plastic tip of a pen to calibrate the Touchscreen. Never use
sharp objects as this will damage the screen.
When this parameter is set to yes, the Offset Pinch Point function is available in the Extra
Bending Parameters.
When this parameter is set to yes, the button up is available when the beam is not at
TDC.
Upward command
The beam goes up as long as the button is pressed.
Go to TDC max
The beam goes to TDC max
Go to next TDC
The beam goes to the next TDC. (first to programmed TDC, then
to the TDC max)
This parameter set the counting mode of the program quantity.
Set to down, The counter will count from top to bottom
Set to up, The counter will count from bottom to top
Set to Autorelaod, The counter will automatically restart the counter once finish
Set to Reset, The counter will need to be reset manually once finish
This function allows choosing the data entry mode for the back gauge on the Bend
Numerical Page or EasyBend Page. When set to yes, the length of the flange icon is
displayed by default. When set to no, the icon for the position in mm of the back gauge
is displayed.
When set to never, the position of the back gauge is no longer linked to the bending
angle, i.e. the position is never recalculated when the bending angle is modified.
The default value for this preference is never. Note that completely formatting
the machine will reset this preference to its default value.
The mode is not available for graphical parts (see also Set point back
gauge (X axis) / flange length).
Touchscreen
Calibration
Offset Pinch Point
function
Show button up
Show L first
Program counter
mode
