5D-Link DAP-2230 User Manual
Section 1 - Product Overview
Hardware Overview
Top Panel
Power/Status LED
1
Static Green Ready/Working Properly
Flashing Green Transmitting/Receiving data
Flashing Red Malfunction during boot
Solid Red Boot failure
1
