D-Link DAP-2230 User Manual

26D-Link DAP-2230 User Manual
Section 3 - Conguration
WPA/WPA2-Enterprise Authentication
WPA Mode: When WPA-Enterprise is selected, you must also select a WPA mode from
the drop-down menu: AUTO (WPA or WPA2), WPA2 Only, or WPA Only.
WPA and WPA2 use dierent algorithms. AUTO (WPA or WPA2) allows you
to use both WPA and WPA2.
Cipher
Type:
When WPA-Enterprise is selected, you must also select a cipher type from
the drop-down menu: Auto, AES, or TKIP.
Group Key
Update
Interval:
Select the interval during which the group key will be valid. The recommended
value is 3600. A lower interval may reduce data transfer rates.
Network
Access
Protection:
Enable or disable Microsoft Network Access Protection.
RADIUS
Server:
Enter the IP address of the RADIUS server.
RADIUS
Port:
Enter the RADIUS port.
RADIUS
Secret:
Enter the RADIUS secret.
WPA/WPA2 Enterprise Authentication can only be enabled for Access Point mode.

D-Link DAP-2230 Specifications

General

Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Wireless Standards	IEEE 802.11n
Ethernet Ports	1 x 10/100 Ethernet
PoE Support	Yes (802.3af)
Operating Modes	Access Point, WDS, Client
Wireless Security	WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Power Supply	12V DC or PoE
