D-Link DAP-2230 User Manual

56D-Link DAP-2230 User Manual
Section 3 - Conguration
Login Page Upload
In this window, users can upload a custom login page picture that will be used by the captive portal feature. Click the Browse
button to navigate to the image le, located on the managing computer and then click the Upload button to initiate the upload.
Upload
from le:
In this eld the path to the image le that will be uploaded will be displayed.
Alternatively, the path can be manually entered here.
Login Page
Style List:
Select the wireless band and login style that will be used for each SSID.
Click the Download button to download the login page template le and
Click the Del button to delete the template le.
Login Page Upload

D-Link DAP-2230 Specifications

General

Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Wireless Standards	IEEE 802.11n
Ethernet Ports	1 x 10/100 Ethernet
PoE Support	Yes (802.3af)
Operating Modes	Access Point, WDS, Client
Wireless Security	WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Power Supply	12V DC or PoE
