D-Link DAP-2230 User Manual

68D-Link DAP-2230 User Manual
Section 3 - Conguration
Client Information
SSID: Displays the SSID of the client.
MAC: Displays the MAC address of the client.
Band: Displays the wireless band that the client is connected to.
Authentication: Displays the type of authentication being used.
Signal: Displays the client's signal strength.
Power
Saving
Mode:
Displays the status of the power saving feature.
This window displays the wireless client information for clients currently connected to the DAP-2230. The following
information is available for each client communicating with the DAP-2230.

D-Link DAP-2230 Specifications

General

Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Wireless Standards	IEEE 802.11n
Ethernet Ports	1 x 10/100 Ethernet
PoE Support	Yes (802.3af)
Operating Modes	Access Point, WDS, Client
Wireless Security	WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Power Supply	12V DC or PoE
