Section 3 - Conguration
Conguration Settings
In the AP array conguration settings windows, users can specify which settings all the APs in the group will inherit from the
master AP. Make the desired selections in this window and click the Save button to accept the changes.
Enable AP
Array
Conguration:
Select to Enable or Disable the AP array congure feature here.
Wireless
Basic
Settings:
Select this option to specify the basic wireless settings that the APs in the
group will inherit.
Wireless
Advanced
Settings:
Select this option to specify the advanced wireless settings that the APs in
the group will inherit.
Multiple
SSID &
VLAN:
Select this option to specify the multiple SSIDs and VLAN settings that the
APs in the group will inherit.
Advanced
Functions:
Select this option to specify the other advanced settings that the APs in the
group will inherit.
Administration
Settings:
Select this option to specify the administrative settings that the APs in the
group will inherit.

D-Link DAP-2230 Specifications

General

Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Wireless Standards	IEEE 802.11n
Ethernet Ports	1 x 10/100 Ethernet
PoE Support	Yes (802.3af)
Operating Modes	Access Point, WDS, Client
Wireless Security	WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Power Supply	12V DC or PoE
