D-Link DAP-2230 User Manual

29D-Link DAP-2230 User Manual
Section 3 - Conguration
IPv6
Enable IPv6: Check to enable the IPv6.
Get IP From: Auto is the default option. The DAP-2230 will get an IPv6 address
automatically or use Static to set IPv6 address manually. When Auto is
selected, the other elds here will be grayed out.
IP Address: Enter the LAN IPv6 address used here.
Prex: Enter the LAN subnet prex length value used here.
Default
Gateway:
Enter the LAN default gateway IPv6 address used here.

D-Link DAP-2230 Specifications

General

Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Wireless Standards	IEEE 802.11n
Ethernet Ports	1 x 10/100 Ethernet
PoE Support	Yes (802.3af)
Operating Modes	Access Point, WDS, Client
Wireless Security	WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Power Supply	12V DC or PoE
