35D-Link DAP-2230 User Manual
Section 3 - Conguration
VLAN
VLAN List
The DAP-2230 supports VLANs. VLANs can be created with a Name and VID. Mgmt (TCP stack), LAN, Primary Multiple SSID, and
WDS connection can be assigned to VLANs as they are physical ports. Any packet which enters the DAP-2230 without a VLAN
tag will have a VLAN tag inserted with a PVID.
The VLAN List tab displays the current VLANs.
VLAN
Status:
Use the radio button to toggle between Enable or Disable. Next, go to the
Add/Edit VLAN tab to add or modify an item on the VLAN List tab.
