D-Link DAP-2230 User Manual

55D-Link DAP-2230 User Manual
Section 3 - Conguration
After selecting POP3 as the Authentication Type, administrators can congure the POP3 authentication settings required to
join the network.
Session
timeout
(1-1440):
Enter the session timeout value here. This value can be from 1 to 1440
minutes. By default, this value is 60 minutes.
Band: Select 2.4 Ghz.
SSID Index: Select the SSID for this Authentication.
Authentication
Type:
Select the captive portal encryption type here. Options to choose from are
Web Redirection, Username/Password, Passcode, Remote RADIUS, LDAP
and POP3.
Web
Redirection
State:
By default web redirection is disabled. Select enable to activate the website
redirection feature.
URL Path : Select whether to use either HTTP or HTTPS here. After selecting either
http:// or https://, enter the URL of the website that will be used in the space
provided.
Server: Enter the POP3 server’s IP address or domain name here.
Port: Enter the POP server’s port number here.
Connection
Type:
Select the connection type here; either None or SSL/TLS.
POP3

D-Link DAP-2230 Specifications

General

Frequency Band	2.4 GHz
Maximum Data Rate	300 Mbps
Wireless Standards	IEEE 802.11n
Ethernet Ports	1 x 10/100 Ethernet
PoE Support	Yes (802.3af)
Operating Modes	Access Point, WDS, Client
Wireless Security	WEP, WPA/WPA2-Personal, WPA/WPA2-Enterprise
Power Supply	12V DC or PoE
