Advanced Configuration Settings
76
DWC-1000 Wireless Controller User’s Guide
2. Under Port Mode, click Load Balancing. Then use the adjacent drop-down list to select
one of the following port balancing methods:
– Round Robin – new connections to the Internet alternate between available links. If
you select this setting, complete the Option Failure Detection Method settings (see
Table
4-5 on page 74).
– Spillover Mode – a single Option link is used for all connections until the bandwidth
threshold is reached, after which point the other Option link is used for new
connections. If you select this setting, complete the Option Failure Detection
Method settings (see Table
4-5) and SPILLOVER CONFIRMATION settings (see
Table
4-6).
3. Click Save Settings.
Table 4-6. SPILLOVER CONFIGURATION Fields
Field Description
Load Tolerance Enter the percentage of maximum bandwidth after which the wireless controller switches to the
secondary Option port.
Max Bandwidth
Enter the maximum bandwidth tolerable by the Primary Option. If the bandwidth falls below the
load tolerance value of configured Max Bandwidth, the wireless controller switches to the
secondary Option port.
