D-Link DWR-956M - Leds

Hardware Overview
LEDs
1.
Power
Solid Blue
Device is powered on.
2.
WAN
Solid Blue
The WAN is properly connected.
Blinking Blue
The WAN is properly connected and data is being transmitted.
OFF
No connection or Cable not connected properly.
3.
LAN 1,2,3,4
Solid Blue
A device is connected to the Ethernet port.
Blinking Blue
A device is connected to the Ethernet port and data is being transmitted.
OFF
Nothing is connected to the Ethernet port.
