VAP (Virtual Access Point) Information
WPS Status: A status of Configured indicates WPS is enabled.
SSID: The name of the SSID.
Authentication Mode: The authentication type to use with the SSID. This can be None,
WEP, WPA-PSK, WPA2-PSK, WPA-PSK/WPA2-PSK MIXED, or 802.1X. Choosing the WEP,
WPA-PSK, WPA2-PSK, WPA-PSK/ WPA2-PSK MIXED, or 802.1X option displays other
options on the page, and these are documented below.
Encryption Mode: The encryption mode for the SSID. This can be AES, TKIP or TKIP+AES.
Click Reset OOB to reset the Out of Band (OOB) access method for the router.
WDS Settings
This allows you to set Wireless Distribution System (WDS) settings for the 2.4GHz and 5 GHz wireless bands.
WDS Settings
Wireless Mode: The wireless mode to enable WDS for. This can be 2.4G or 5G.
WDS Mode: The WDS mode. This can be Disabled, Lazy Mode, Repeater Mode,
Bridge Mode. The default is Disabled.
Choosing the Lazy Mode, Repeater Mode, or Bridge Mode option displays other
options on the page, and these are documented below.
WDS Mode: Lazy Mode
WDS Security: The WDS security type. This can be None, WEP, TKIP or AES.
Choosing the WEP, TKIP or AES option displays other options on the page, and
these are documented below.
WDS Mode: Repeater Mode or Bridge Mode
AP1 MAC Address: The MAC address of AP 1 in the WDS.
AP2 MAC Address: The MAC address of AP 2 in the WDS.
AP3 MAC Address: The MAC address of AP 3 in the WDS.
