76D-Link DWR-961 User Manual
Section 3 - Conguration
Type: Select an EtherType from the dropdown menu to which the rule
will apply.
Protocol: Select a protocol from the dropdown menu to which the rule will
apply.
Position: Rules are evaluated based on position starting with rule 0.
The rules are applied from lowest to highest until the rules are
exhausted or one is triggered.
Condition: Indicates a python logical operator to be performed on the
value.
Value: Indicates the value the rule will use to evaluate trigger
conditions.
Rule Action: Indicates the action taken when the rule is triggered.
Action: Click the pencil (
) icon to edit the rule, click the trash can icon (
) to delete the rule.
Click Add to add a new generic rule, described in Packet Filter -- Generic Rules
on page 80.
