cfm linktrace
Purpose
Used to transmit a CFM linktrack message.
Syntax cfm linktrace <macaddr> [mepname <string 32> | mepid <int 1-8191> md <string 22>
ma <string 22>] {ttl <int 2-255> | pdu_priority <int 0-7>}
Description
This command is used to issue a CFM linktrack message.
Parameters <macaddr> – Specifies the destination MAC address.
mepname – Specifies the MEP name.
mepid – Specifies the MEP MEPID.
md – Specifies the maintenance domain name.
ma – Specifies the maintenance association name.
ttl – Specifies the linktrace message TTL value. The default value is 64.
pdu_priority – The 802.1p priority to be set in the transmitted LTM. If not specified, it uses the
same priority as CCMs sent by the MA.
Restrictions
None.
Example usage:
To create a cfm linktrace:
DES-3528:admin# cfm linktrace 00-01-02-03-04-05 mep mep1
Command: cfm linktrace 00-01-02-03-04-05 mep mep1
Transaction ID: 26
Success.
DES-3528:admin#
show cfm linktrace
Purpose
Used to show linktrace responses.
Syntax show cfm linktrace [mepname <string 32> | mepid <int 1-8191> md <string 22> ma
<string 22>] {trans_id <uint>}
Description
The maximum linktrace responses a device can hold is 64.
Parameters mepname – Specifies the MEP name.
mepid – Specifies the MEP MEPID.
md – Specifies the maintenance domain name.
ma – Specifies the maintenance association name.
trans_id – Specifies the identifier of the transaction to show.
Restrictions
None.
Example usage:
To display the cfm linktrace:
