SiEBE18-526 Field Setting for SkyAir Indoor Unit
Test Operation 129
4.2 Field Setting
4.2.1 Wired Remote Controller
Note: (Field setting must be made from the remote controller in accordance with the installation
conditions.)
Setting can be made by changing the “Mode number”, “FIRST CODE NO.”, and “SECOND
CODE NO.”.
Refer to the following procedures for Field setting.
Procedure
When in the normal mode, press the “”button for a minimum of four seconds, and the FIELD
SET MODE is entered.
During group control, when setting by each indoor unit (mode No. 20, 21 and 23 have been
selected), push the “”button and select the INDOOR UNIT NO to be set. (This operation is
unnecessary when setting by group.)
Select the desired MODE NO. with the “”button.
Push the “”button for about one second to return to the NORMAL MODE.
(Example) If during gro
up setting and the time to clean air filter isset to FILTER CONTAMINATION -
HEAVY, SET MODE NO. to “10,” FIRST CODE NO. to “0,”and SECOND CODE NO. to “02.”
Push the “”button once and the present settingsare SET.
Push the “” lower button and select the SECOND CODE NO.
Push the “”upper
button and select FIRST CODE NO.
UNIT NO.
MODE NO.
SECOND
CODE NO.
FIRST
CODE NO.
FIELD
SET
MODE
2P068938-1
To Next Page
