Daikin Super Multi Plus D-Series User Manual

Piping Diagrams SiEBE18-526
362 Appendix
1.3 Indoor Units
1.3.1 Wall Mounted Type
FTXS20/25/35D(2)VMW(L)(9)
FTXS20/25/35DA(3)VMW(L)(7)
CTXS50D(2)VMW(L)
FTXS20/25/35CVMB(9)(8)
FTXS20/25/35CAVMB
FTXS50/60BVMB
4D047912A
FIELD PIPING
FIELD PIPING
(
6.4CuT
)
(
9.5CuT
)
7.9CuT
MAFFLER ASSY
CROSS FLOW FAN
FAN MOTOR
INDOOR UNIT
M
6.4CuT
7.0CuT
9.5CuT
HEAT EXCHANGER
REFRIGERANT FLOW
HEATING
COOLING
6.4CuT
6.4CuT
THERMISTOR
ON HEAT EXCH.
M
4D047913A
FIELD PIPING
FIELD PIPING
(
6.4CuT
)
(
9.5CuT
)
7.9CuT
MAFFLER ASSY
CROSS FLOW FAN
FAN MOTOR
INDOOR UNIT
6.4CuT
7.0CuT
9.5CuT
HEAT EXCHANGER
REFRIGERANT FLOW
HEATING
COOLING
6.4CuT
6.4CuT
THERMISTOR
ON HEAT EXCH.
7.9CuT
CROSS FLOW FAN
FAN MOTOR
M
INDOOR UNIT
7.0CuT
6.4CuT
9.5CuT
HEAT EXCHANGER
6.4CuT
6.4CuT
THERMISTOR
ON HEAT EXCH.
FIELD PIPING
(6.4CuT)
FIELD PIPING
(9.5CuT)
REFRIGERANT FLOW
COOLING
HEATING
4D049319
FIELD PIPING
FIELD PIPING
(12.7CuT)
(6.4CuT)
CROSS FLOW FAN
FAN MOTOR
(7.9CuT)
INDOOR UNIT
(12.7CuT)
M
HEAT EXCHANGER
REFRIGERANT FLOW
COOLING
HEATING
4D040081J
THERMISTOR
ON HEAT
EXCH.
