Daikin Super Multi Plus D-Series User Manual

SiEBE18-526 Special Control
Function 61
3. Special Control
3.1 Startup Control
On activation, following control is performed to lighten load of the compressor by back liquid and
the like. Also, the position of the four way valve is defined.
3.1.1 Startup Control in Cooling Operation
3.1.2 Startup Control in Heating Operation
Actuator Operation Remarks
Compressor Differential pressure control
Compressor operating frequency
increases by 2 step / 20 sec until
Pc - Pe>0.4 MPa.
Outdoor unit fan High pressure control
Initial fan speed is set to STEP 0
(Ta
<20°C), or STEP 7 (Ta≥).
Four way valve OFF ⎯
Main electronic expansion valve (EV1) 2000 pls ⎯
Subcooling electronic expansion valve
(EV2)
0 pls ⎯
Hot gas bypass valve (SVP) ON ⎯
Receiver gas discharging valve (SVG) OFF ⎯
Ending conditions
• 255 sec.
• Pc - Pe>0.4 MPa
• 75 sec
BP unit electronic expansion valve
(operating room)
0 pls ⎯
BP unit electronic expansion valve
(stopping room)
0 pls ⎯
Actuator Operation Remarks
Compressor Differential pressure control
Compressor operating frequency
increases by 2 step / 20 sec until
Pc - Pe>0.4 MPa.
Outdoor unit fan STEP8 ⎯
Four way valve ON ⎯
Main electronic expansion valve (EV1) 180 pls ⎯
Subcooling electronic expansion valve
(EV2)
0 pls ⎯
Hot gas bypass valve (SVP) ON ⎯
Receiver gas discharging valve (SVG) ON ⎯
Ending conditions
• 225 sec.
• Pc - Pe>0.4 MPa
• 40 sec
BP unit electronic expansion valve
(operating room)
0 pls ⎯
BP unit electronic expansion valve
(stopping room)
0 pls ⎯
