Troubleshooting for Outdoor Unit SiEBE18-526
302 Troubleshooting
7.9 Malfunction of Discharge Pipe Thermistor (R3T)
Remote
Controller
Display
J3
Applicable
Models
AII outdoor unit models
Method of
Malfunction
Detection
Malfunction is detected from the temperature detected by discharge pipe temperature
thermistor.
Malfunction
Decision
Conditions
When a short circuit or an open circuit in the discharge pipe temperature thermistor is detected.
Supposed
Causes
Defect of thermistor (R3T) for outdoor unit discharge pipe
Defect of outdoor unit PCB (A1P)
Troubleshooting
∗ Refer to thermistor resistance / temperature characteristics table on P326.
(Q0429)
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Resistance
is normal when
measured after
disconnecting the thermistor
R3T from the outdoor
unit PCB.
(3.5kΩ~
400kΩ)
Replace outdoor unit PCB A1P.
Connect the thermistor and turn
on again.
NO
NO
Replace the thermistor (R3T)
YES
YES
Connector
is connected to
outdoor unit
PCB
(A1P).
To Next Page
