Instruction SiEBE18-526
170 System Configuration
2.2.6 Adjusting the Air Flow Direction
FTXS20/25/35D, CTXS50D
TEMP
ON/OFF
POWERFUL
MODE
FA N
SWING
SILENT
SENSOR
ECONO
COMFORT
TIMER
ON
CANCEL
OFF
1, 2
3, 4
Adjusting the Air Flow Direction
Yo u can adjust the air flow direction to increase your comfort.
To adjust the horizontal
blades (flaps)
1. Press “SWING button”.
2. When the flaps have reached the
desired position, press “SWING
button” once more.
The display will go blank.
The flaps will stop moving.
• “” is displayed on the LCD and the flaps
will begin to swing.
To adjust the vertical blades
(louvers)
Hold the knoband move the louvers.
(You will find a knob on the left-side and the right-side blades.)
• When the unit is installed in the corner of a room,
the direction of the louversshould be facing away
from the wall.
If they face the wall, the wall will block off the wind,
causing the cooling (or heating) efficiency to drop.
