Printed Circuit Board Connector Wiring Diagram SiEBE18-526
40 Printed Circuit Board Connector Wiring Diagram and Name
1.10 Ceiling Suspended Type
Connectors
1) X5A Connector for Terminal Strip (for Wired Remote Controller)
2) X14A Connector for Limit Switch (for Swing Flap)
3) X15A Connector for Drain Pump (Optional Accessory)
4) X17A Connector for Heat Exchanger Thermistor (2)
5) X18A Connector for Heat Exchanger Thermistor (1)
6) X19A Connector for Room Temperature Thermistor
7) X20A, X26A Connector for Fan Motor
8) X24A Connector for Wireless Remote Controller Receiver Unit
9) X25A Connector for Drain Pump Motor (Optional Accessory)
10) X27A Connector for Terminal Strip (for Inter Unit Wiring)
11) X29A Connector for Swing Motor
12) X33A Connector for Wring Adaptor PCB (Optional Accessory)
13) X35A Connector for Group Control Adaptor (Optional Accessory)
14) X40A Connector for ON/OFF Input from Outside (for Optional Accessory)
15) X60A, X61A Connector for Interface Adaptor (Optional Accessory)
Note: Other Designation
1) HAP Service Monitor LED
To Next Page
