SiEBE18-526 Specifications
Specifications 9
1.2 BP Unit
50Hz 230V
Note:
1. BP or Indoor Unit Max. Height - BP or Indoor Unit Min. Height → Max. 15m.
Set up BP and indoor unit within 15m height difference.
2. The piping connection must be cut so as to suit the piping sizes of the indoor unit which will be connected.
The same sizes should be used for the piping on the outdoor unit.
3. ( )*: including auxiliary piping length
Model BPMKS967A2B, BPMKS967B2B BPMKS967A3B, BPMKS967B3B
Connectable Indoor Units 1~2 Units 1~3 Units
Casing Color Paintingless
Power Consumption W 10 10
Running Current A 0.05 0.05
Refrigerant Type R410A
Dimension (H×W×D) mm 180×294(650)*×350
Package Dimension (H×W×D) mm 257×738×427
Machine Weight kg 7.5 8
Gross Weight kg 11 12
Number of Wiring Connections 4 for Interunit Wiring
Piping
Connection
(Brazing)
Liquid mm Main : φ9.5×1/ Branch : φ6.4×2 Main : φ9.5×1/ Branch : φ6.4×3
Gas mm Main : φ19.1×1 / Branch : φ15.9×2 Main : φ19.1×1 / Branch : φ15.9×3
Drain mm Drain Processingless
Heat Insulation Both Liquid and Gas Pipes
Max. Piping Length m —
Amount of Additional Charge g/m —
Max. Height Difference m —
Max. Combination kW 14.2 20.8
Min. Combination kW 2.0 2.0
Accessories
Installation Manual pc. 1
L Shape Reducer pc.
For Main
Liquid 1 (O.D. φ9.5 to I.D. φ6.4)
Gas 1 (O.D. φ15.9 to I.D. φ12.7)
Gas 1 (O.D. φ19.1 to I.D. φ15.9, 19.1)
For Branch
Liquid
2 (O.D. φ15.9 to I.D. φ12.7,
9.5)
3 (O.D. φ15.9 to I.D. φ12.7, 9.5)
Gas 1 (O.D. φ6.4 to I.D. φ9.5)
Hanger Metal pc. 4
Screws pc. 8 (M4×8)
Heat Insulation (2pc. is 1 set) 3 Set 4 Set
Binding Band pc. 2
Drawing No. 4D050058
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
