Daikin Super Multi Plus D-Series - Pressure Sensor

Pressure Sensor SiEBE18-526
328 Troubleshooting
10.Pressure Sensor
High Pressure (PH)
Low Pressure (P
L)
PH : Detected Pressure [High Side] MPa
P
L : Detected Pressure [Low Side] MPa
V
H : Output Voltage [High Side] VDC
VL : Output Voltage [Low Side] VDC
PH = 1.38V-0.69
P
L = 0.57V-0.28
P
H : High pressure (MPa)
V
L : Low pressure (MPa)
V : Voltage (V)
Output Voltage (V
H, VL)
Detected Pressure
(V3053)
PH, PL
MPa
5.051.0
45.9
40.8
35.7
4.5
4.0
3.5
30.6
3.0
25.5
2.5
20.4
2.0
15.3
1.5
10.2
1.0
5.1
0.5
0
-5.1
-0.5
-0.5 1.510.50 2.52 3.53 4
V
DC
(kg/cm³)
