Test Operation and Field Setting for RA Indoor Unit SiEBE18-526
140 Test Operation
5.2.3 Adjusting the Angle of the Intelligent Eye Sensor
FTXS20-35C
Once installation of the indoor unit is complete, adjust the angle of the Intelligent eye sensor
to ensure the detection area properly covers the room.
(Adjustable angle : 15° to right and left of center)
Gently push and slide the sensor to adjust the angle. Aim so that the sensor is pointing to the
center of the room, or to the part of the room that is most frequently used.
After adjusting the angle, gently wipe the sensor with a clean cloth, being careful not to
scratch the sensor.
Caution Do not hit or violently push the Intelligent eye sensor. This can lead to damage and
malfunction.
Do not place large objects near the sensor. Also keep heating units or humidifiers outside
the sensor’s detection area.
(R1729)
Intelligent-eye
sensor
15° 15°
(R1730)
Moving the sensor to the left Moving the sensor to the right
To Next Page
