SiEBE18-526 Instruction
System Configuration 173
0˚
25˚
5˚
30˚
To adjust the vertical blades
(louvres)
Hold the knoband move the louvres.
(You will find a knob on the left-side and the right-side blades.)
Notes on flaps and louvres angles
• When “SWING button” isselected, the flaps
swinging range depends on the operation mode.
(See the figure.)
ATTENTION
• Alwaysuse a remote control to adjust the flaps
angle. If youattempt to move it forcibly with hand
when it isswinging, the mechanism may be broken.
• Be careful when adjusting the louvres. Inside the
air outlet, a fan is rotating at a high speed.
In DRY mode or COOL mode
In HEAT or FAN mode
When stop operation
When stop operation
Upper limit in cooling
Upper limit in heating
Lower limit in cooling
Lower limit in heating
