SiEBE18-526 Instruction
System Configuration 175
To 3-D Airflow
To cancel 3-D Airflow
1. 3. Press the “SWING button ” and the “SWING button ”:
the “ ” and “ ” display will light up and the flap and louvers will
move in turn.
2. 4. Press either the “SWING button ” or the “SWING button ”
Notes on louvers angles
Notes on flap angle
ATTENTION
• Alwaysuse a remote control to adjust the louversangles. In side the air outlet, a fan is rotating at a
high speed.
•
When “
SWING button
” isselected, the flapsswinging
range depends on the operation mode. (See the figure.
)
Three-Dimensional (3-D) Airflow
•
Using three-dimensional airflow circulates cold air,
which tends to collected at the bottom of the room, and
hot air, which tends to collect near the ceiling,
throughout the room, preventing areas of cold and hot
developing.
ATTENTION
•
Alwaysuse a remote controller to adjust the flapsangle.
If youattempt to move it forcibly with hand when it is
swinging, the mechanism may be broken.
•
Be careful when adjusting the louvers . Inside the air
outlet, fan is rotating at a high speed.
In COOL or DRY mode
In HEAT or FAN mode
HEAT
approx. 15˚~55˚
FAN
approx. 5˚~55˚
STOP
STOP
COOL
approx. 10˚~40˚
DRY
approx. 5˚~35˚
