SiEBE18-526 Instruction
System Configuration 201
Filters
1. Open the front grille.
2. Pull out the air filters.
•
Push a little upwards the tab at the center of
each air filter, then pull it down.
3. Take off the air
purifying filter with
photocatalytic
deodorizing function.
• Press the top of the
aircleaning filter onto the
tabs (3 tabs at top). Then
press the bottom of the
filter up slightly, and press
it onto the tabs (2 at
bottom) (3at bottom).
4.
Clean or replace each filter.
See below.
5. Set the air filter, air purifying filter with
photocalytic deodorizing function as they
were and close the front grille.
• Press the front panel at both sidesand the center.
Air Filter
Air purifying filter with photocatalytic deodorizing function. (gray)
1.
Wash the air filters with water or clean them with vacuum cleaner.
•
If the dust does not come off easily, wash them with neutral detergent
thinned with lukewarm water, then dry them up in the shade.
•
It is recommended to clean the air filters every two weeks.
The air purifying filter with photocatalytic deodorizing function can be renewed by washing it with
water once every 6 months. We recommend replacing it once every 3 years.
[ Maintenance ]
[ Replacement]
1. Remove dust with a vacuum cleaner and wash lightly with water.
2.
If it is very dirty, soak it for 10 to 15 minutes in water mixed with a neutral cleaning agent.
3. After washing, shake off remaining water and dry in the shade.
4.
Since the material is made out of paper, do not wring out the filter when removing water from it.
1. Remove the tabs on the filter frame and replace with a new filter.
• Dispose of the old filter as flammable waste.
tabs (3 tabs at top)
tabs (2 at bottom)
50class
tabs (3 tabs at top)
tabs (3at bottom)
60,71class
