SiEBE18-526 Specifications
Specifications 11
50Hz 230V
Model
FTXS35D(2)VMW(9), FTXS35DA(3)VMW(7) FTXS35D(2)VML, FTXS35DA(3)VML
Cooling Heating Cooling Heating
Rated Capacity 3.5kW Class 3.5kW Class
Front Panel Color White Silver Line
Air Flow Rates
m³/min
(cfm)
H 8.9 (314) 9.7 (342) 8.9 (314) 9.7 (342)
M 6.9 (244) 7.9 (279) 6.9 (244) 7.9 (279)
L 4.8 (169) 6.0 (212) 4.8 (169) 6.0 (212)
SL 4.0 (141) 5.2 (184) 4.0 (141) 5.2 (184)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.18 0.18 0.18
Power Consumption (Rated) W 40 40 40 40
Power Factor % 96.6 96.6 96.6 96.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 39/26/23 39/29/26 39/26/23 39/29/26
Sound Power H dBA 57 57 57 57
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ 9.5 φ 9.5
Drain mm
φ18.0 φ18.0
Drawing No. 3D048875A 3D049114A
Model
CTXS50D(2)VMW CTXS50D(2)VML
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 5.0kW Class
Front Panel Color White Silver Line
Air Flow Rates
m³/min
(cfm)
H 11.4 (402) 11.4 (402) 11.4 (402) 11.4 (402)
M 9.3 (328) 9.4 (332) 9.3 (328) 9.4 (332)
L 7.1 (251) 7.4 (261) 7.1 (251) 7.4 (261)
SL 6.2 (219) 6.3 (222) 6.2 (219) 6.3 (222)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 40
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.21 0.21 0.21 0.21
Power Consumption (Rated) W 48 48 48 48
Power Factor % 99.4 99.4 99.4 99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 283×800×195 283×800×195
Packaged Dimensions (H×W×D) mm 265×855×340 265×855×340
Weight kg 9 9
Gross Weight kg 12 12
Operation
Sound
H/L/SL dBA 46/35/32 44/33/30 46/35/32 44/33/30
Sound Power H dBA 64 62 64 62
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ12.7 φ12.7
Drain mm
φ18.0 φ18.0
Drawing No. 3D049115A 3D049116A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
