SiEBE18-526 Specifications
Specifications 13
50Hz 230V
Model
FTXS60BVMB FTXS71BVMB
Cooling Heating Cooling Heating
Rated Capacity 6.0kW Class 7.1kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 16.2 (572) 17.4 (614) 16.7 (590) 18.5 (653)
M 13.6 (480) 15.1 (533) 14.2 (501) 15.1 (533)
L 11.4 (402) 12.7 (448) 11.6 (409) 13.5 (477)
SL 10.2 (360) 11.4 (402) 10.6 (374) 12.1 (427)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 43 43
Speed Steps 5 Steps, Silent, Auto 5 Steps, Silent, Auto
Air Direction Control Right, Left, Horizontal, Downward Right, Left, Horizontal, Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.18 0.20 0.20 0.22
Power Consumption (Rated) W 40 45 45 50
Power Factor % 96.6 97.8 96.4 97.6
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238 290×1,050×238
Packaged Dimensions (H×W×D) mm 337×1,147×366 337×1,147×366
Weight kg 12 12
Gross Weight kg 17 17
Operation
Sound
H/M/L/SL dBA 45/41/36/33 44/40/35/32 46/42/37/34 46/42/37/34
Sound Power H dBA 63 62 63 63
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ12.7 φ15.9
Drain mm
φ18.0 φ18.0
Drawing No. 3D040779 3D040780A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
