ADJUSTMENT
For programming TEMPERATURE, FAN SPEED
and AIR FLOW DIRECTION, follow the procedure
shown below.
TEMPERATURE SETTING
Press TEMPERATURE SETTING button and
program the setting temperature.
Each time thisbutton is pressed, setting
temperature rises 1°C.
Each time thisbutton is pressed, setting
temperature lowers 1°C.
• The setting is impossible for fan opera tion.
NOTE
• The setting temperature range of the remote
control is 16°C to 32°C.
FAN SPEED CONTROL
Press FAN SPEED CONTROL button.
High or Low fan speed can be selected.
The micro computer may sometimes control the fan
speed in order to protect the unit.
AIR FLOW DIRECTION ADJUST
• There are 2 ways of adjusting the air discharge
angle.
1. A. Up and down adjustment
2. B. Left and right direction
Fig. 1
A. Up and down
direction
B. Left and right direction
A. UP AND DOWN DIRECTION
• The movable limit of the flap is changeable.
Contact your Daikin dealer for details.
Press the AIR FLOW DIRECTION ADJUST
button to select the air direction as follow-
ing.
The AIR FLOW FLAP display
swingsasshown the left and
the air flow direction continu-
ously varies. (Automatic swing
setting)
Press AIR FLOW DIRECTION
ADJUST button to select the air
direction of your choice.
The AIR FLOW FLAP display
stopsswinging and the air flow
direction is fixed (Fixed air flow
direction setting).
MOVEMENT OF THE AIR FLOW FLAP
For the following conditions, micro computer
controls the air flow direction so it may be different
from the display.
Operation mode includesautomatic operation.
B. LEFT AND RIGHT DIRECTION
• Adjusting air flow direction in the left and right
direction. (Refer to Fig. 1)
NOTE
• Only make adjustmentsafter you have stopped
the air flow direction swing in a position where
adjustmentsare possible. Your hand may get
caught if youattempt to make adjustments while
the unit isswinging.
Operation
mode
Cooling
Heating
Operation
condition
• When room
temperature is
lower than the
set temperature
•
When room
temperature is
higher than the
set temperature
•
At defrost
operation
• When operating continuously at
downward air flow direction
