SiEBE18-526 Outdoor Unit
Removal Procedure 331
2. Removing the rear
protective net
1
Undo the three top
hooks first.
Bend the rear protective net
slightly for easy removal.
2
Next, undo the four
right-side hooks. (See
the figure at bottom.)
3
Remove the rear
protective net.
Step
Procedure Points
Hooks
(Q0448)
(Q0449)
(Q0450)
Hooks
