Outdoor Unit SiEBE18-526
352 Removal Procedure
3
Open the fan motor
lead fixture.
When reassembling, make sure
the lead wires are fastened by
the fixtures.
4
Remove the four
screws and take out the
fan motor.
Remove the two bottom screws
first. If the top two screws are
removed first, the fan motor may
tilt down or fall by gravity,
getting you injured.
Step
Procedure Points
(Q0499)
(Q0500)
To Next Page
