Piping Diagrams SiEBE18-526
366 Appendix
1.3.5 Ceiling Mounted Cassette Type
FFQ25/35/50/60B7V1B
1.3.6 Ceiling Suspended Type
FHQ35/50/60BUV1B9
9.5
12.76.4
6.4
MODEL
FFQ50 · 60B7V1B
FFQ25 · 35B7V1B
Field piping φ C1220T-O
Field piping φ C1220T-O
Indoor unit
Indoor heat exchanger
C : 4D039335
To
Outdoor unit
Indoor heat exchanger
6.4
6.4
9.5
12.7
15.9
9.5
4D037995E
Indoor unit
MODEL
FUQ71, 100, 125BUV1B
FHQ71, 100, 125BUV1B
FAQ71, 100BUV1B
FXUQ70, 100, 125MV1
FHQ71, 100, 125BAV3B
FCQ71, 100, 125, 140DV3B
FCQ71BVE
FBQ71BV1, FBQ71BVL
FHQ50 · 60BUV1B
FCQ50 · 60BVE
FBQ60BV1, FBQ60BVL
FHQ35BUV1B
FCQ35BVE
To
Outdoor unit
Field piping φ C1220T-0
Field piping φ C1220T-0
