18-12 Emergency Mode Log: Date and Time
Range: Function:
Size
related*
[ 0 -
0 ]
This parameter contains an array with 10
elements. The parameter shows at which
date and time the logged event occurred.
The function relies on the fact that the actual
date and time has been set in
parameter 0-70 Date and Time. Note: There is
no built-in battery back-up of the clock. Use
an external back-up, for example the one in
the VLT
®
Analog I/O MCB 109 Analog I/O
option card. See parameter group 0-7* Clock
Settings.
3.16.3 18-3* Analog Readouts
18-30 Analog Input X42/1
Range: Function:
0* [-20 -
20 ]
Readout of the value of the signal applied to
terminal X42/1 on the VLT
®
analog I/O card MCB
109.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-00 Terminal X42/1 Mode.
18-31 Analog Input X42/3
Range: Function:
0* [-20 -
20 ]
Readout of the value of the signal applied to
terminal X42/3 on the VLT
®
analog I/O card MCB
109.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-01 Terminal X42/3 Mode.
18-32 Analog Input X42/5
Range: Function:
0* [-20 -
20 ]
Readout of the value of the signal applied to
terminal X42/5 on the VLT
®
analog I/O card MCB
109.
The units of the value shown in the LCP
correspond to the mode selected in
parameter 26-02 Terminal X42/5 Mode.
18-33 Analog Out X42/7 [V]
Range: Function:
0* [0 - 30 ] Readout of the value of the signal applied to
terminal X42/7 on the VLT
®
analog I/O card MCB
109.
The value shown reects the selection in
parameter 26-40 Terminal X42/7 Output.
18-34 Analog Out X42/9 [V]
Range: Function:
0* [0 - 30 ] Readout of the value of the signal applied to
terminal X42/9 on the VLT
®
analog I/O card MCB
109.
The value shown reects the selection in
parameter 26-50 Terminal X42/9 Output.
18-35 Analog Out X42/11 [V]
Range: Function:
0* [0 - 30 ] Readout of the value of the signal applied to
terminal X42/11 on the VLT
®
analog I/O card MCB
109.
The value shown reects the selection in
parameter 26-60 Terminal X42/11 Output.
18-36 Analog Input X48/2 [mA]
Range: Function:
0* [-20 - 20 ] View the actual current measured at input X48/2
(VLT
®
Sensor Input Card MCB 114).
18-37 Temp. Input X48/4
Range: Function:
0* [-500 -
500 ]
View the actual temperature measured at input
X48/4 (VLT
®
Sensor Input Card MCB 114). The
temperature unit is based on the selection in
parameter 35-00 Term. X48/4 Temperature Unit.
18-38 Temp. Input X48/7
Range: Function:
0* [-500 -
500 ]
View the actual temperature measured at input
X48/7 (VLT
®
Sensor Input Card MCB 114). The
temperature unit is based on the selection in
parameter 35-02 Term. X48/7 Temperature Unit.
18-39 Temp. Input X48/10
Range: Function:
0* [-500 -
500 ]
View the actual temperature measured at input
X48/10 (VLT
®
Sensor Input Card MCB 114). The
temperature unit is based on the selection in
parameter 35-04 Term. X48/10 Temperature Unit.
18-50 Sensorless Readout [unit]
Range: Function:
0 SensorlessUnit* [-999999.999 - 999999.999
SensorlessUnit]
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 157
3 3
