4.1.4 2-** Brakes
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
2-0* DC-Brake
2-00 DC Hold/Preheat Current 50% All set-ups TRUE 0 Uint8
2-01 DC Brake Current 50% All set-ups TRUE 0 Uint16
2-02 DC Braking Time 10 s All set-ups TRUE -1 Uint16
2-03 DC Brake Cut In Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
2-04 DC Brake Cut In Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
2-06 Parking Current 50% All set-ups TRUE 0 Uint16
2-07 Parking Time 3 s All set-ups TRUE -1 Uint16
2-1* Brake Energy Funct.
2-10 Brake Function ExpressionLimit All set-ups TRUE - Uint8
2-11 Brake Resistor (ohm) ExpressionLimit All set-ups TRUE 0 Uint16
2-12 Brake Power Limit (kW) ExpressionLimit All set-ups TRUE 0 Uint32
2-13 Brake Power Monitoring [0] O All set-ups TRUE - Uint8
2-15 Brake Check [0] O All set-ups TRUE - Uint8
2-16 AC brake Max. Current 100% All set-ups TRUE -1 Uint32
2-17 Over-voltage Control [2] Enabled All set-ups TRUE - Uint8
Parameter Lists Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 253
