Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
1-60 Low Speed Load Compensation 100% All set-ups TRUE 0 Int16
1-61 High Speed Load Compensation 100% All set-ups TRUE 0 Int16
1-62 Slip Compensation 0% All set-ups TRUE 0 Int16
1-63 Slip Compensation Time Constant ExpressionLimit All set-ups TRUE -2 Uint16
1-64 Resonance Damping 100% All set-ups TRUE 0 Uint16
1-65 Resonance Damping Time Constant 5 ms All set-ups TRUE -3 Uint8
1-66 Min. Current at Low Speed ExpressionLimit All set-ups TRUE 0 Uint8
1-7* Start Adjustments
1-70 PM Start Mode ExpressionLimit All set-ups TRUE - Uint8
1-71 Start Delay 00 s All set-ups TRUE -1 Uint16
1-72 Start Function ExpressionLimit All set-ups TRUE - Uint8
1-73 Flying Start ExpressionLimit All set-ups FALSE - Uint8
1-77 Compressor Start Max Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-78 Compressor Start Max Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-79 Pump Start Max Time to Trip 0 s All set-ups TRUE -1 Uint16
1-8* Stop Adjustments
1-80 Function at Stop [0] Coast All set-ups TRUE - Uint8
1-81
Min Speed for Function at Stop
[RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-82 Min Speed for Function at Stop [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-86 Trip Speed Low [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-87 Trip Speed Low [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-9* Motor Temperature
1-90 Motor Thermal Protection ExpressionLimit All set-ups TRUE - Uint8
1-91 Motor External Fan [0] No All set-ups TRUE - Uint8
1-93 Thermistor Source [0] None All set-ups TRUE - Uint8
1-94 ATEX ETR cur.lim. speed reduction 0% 2 set-ups TRUE -1 Uint16
1-98 ATEX ETR interpol. points freq. ExpressionLimit 1 set-up TRUE -1 Uint16
1-99 ATEX ETR interpol points current ExpressionLimit 2 set-ups TRUE 0 Uint16
Parameter Lists
VLT
®
AQUA Drive FC 202
252 Danfoss A/S © 05/2018 All rights reserved. MG20OB02
44
