4.1.3 1-** Load and Motor
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
1-0* General Settings
1-00 Conguration Mode ExpressionLimit All set-ups TRUE - Uint8
1-01 Motor Control Principle [1] VVC+ All set-ups FALSE - Uint8
1-03 Torque Characteristics
[3] Auto Energy
Optim. VT All set-ups TRUE - Uint8
1-04 Overload Mode [1] Normal torque All set-ups FALSE - Uint8
1-06 Clockwise Direction [0] Normal All set-ups FALSE - Uint8
1-1* Motor Selection
1-10 Motor Construction [0] Asynchron All set-ups FALSE - Uint8
1-1* VVC+ PM/SYN RM
1-14 Damping Gain ExpressionLimit All set-ups TRUE 0 Int16
1-15 Low Speed Filter Time Const. ExpressionLimit All set-ups TRUE -2 Uint16
1-16 High Speed Filter Time Const. ExpressionLimit All set-ups TRUE -2 Uint16
1-17 Voltage lter time const. ExpressionLimit All set-ups TRUE -3 Uint16
1-2* Motor Data
1-20 Motor Power [kW] ExpressionLimit All set-ups FALSE 1 Uint32
1-21 Motor Power [HP] ExpressionLimit All set-ups FALSE -2 Uint32
1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0 Uint16
1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-24 Motor Current ExpressionLimit All set-ups FALSE -2 Uint32
1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67 Uint16
1-26 Motor Cont. Rated Torque ExpressionLimit All set-ups FALSE -1 Uint32
1-28 Motor Rotation Check [0] O All set-ups FALSE - Uint8
1-29 Automatic Motor Adaptation (AMA) [0] O All set-ups FALSE - Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) ExpressionLimit All set-ups FALSE -4 Uint32
1-31 Rotor Resistance (Rr) ExpressionLimit All set-ups FALSE -4 Uint32
1-33 Stator Leakage Reactance (X1) ExpressionLimit All set-ups FALSE -4 Uint32
1-34 Rotor Leakage Reactance (X2) ExpressionLimit All set-ups FALSE -4 Uint32
1-35 Main Reactance (Xh) ExpressionLimit All set-ups FALSE -4 Uint32
1-36 Iron Loss Resistance (Rfe) ExpressionLimit All set-ups FALSE -3 Uint32
1-37 d-axis Inductance (Ld) ExpressionLimit All set-ups FALSE -6 Int32
1-38 q-axis Inductance (Lq) ExpressionLimit All set-ups FALSE -6 Int32
1-39 Motor Poles ExpressionLimit All set-ups FALSE 0 Uint8
1-40 Back EMF at 1000 RPM ExpressionLimit All set-ups FALSE 0 Uint16
1-44 d-axis Inductance Sat. (LdSat) ExpressionLimit All set-ups FALSE -6 Int32
1-45 q-axis Inductance Sat. (LqSat) ExpressionLimit All set-ups FALSE -6 Int32
1-46 Position Detection Gain 100% All set-ups TRUE 0 Uint16
1-47 Torque Calibration [0] O All set-ups TRUE - Uint8
1-48 Inductance Sat. Point ExpressionLimit All set-ups FALSE 0 Int16
1-5* Load Indep. Setting
1-50 Motor magnetization at Zero Speed 100% All set-ups TRUE 0 Uint16
1-51
Min Speed Normal Magnetizing
[RPM] ExpressionLimit All set-ups TRUE 67 Uint16
1-52 Min Speed Normal Magnetizing [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
1-55 V/f Characteristic - V ExpressionLimit All set-ups TRUE -1 Uint16
1-56 V/f Characteristic - f ExpressionLimit All set-ups TRUE -1 Uint16
1-58 Flying Start Test Pulses Current ExpressionLimit All set-ups FALSE 0 Uint16
1-59 Flying Start Test Pulses Frequency ExpressionLimit All set-ups FALSE 0 Uint16
1-6* Load Depen. Setting
Parameter Lists Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 251
