Danfoss VLT AQUA Drive FC 202 Programming Guide

3.15 Parameters 16-** Data Readouts
3.15.1 16-0* General Status
16-00 Control Word
Range: Function:
0* [0 - 65535 ] View the control word sent from the frequency
converter via the serial communication port in
hex code.
16-01 Reference [Unit]
Range: Function:
0 ReferenceFeed-
backUnit*
[-999999 -
999999
ReferenceFeed-
backUnit]
View the present reference
value applied on impulse or
analog basis in the unit
resulting from the congu-
ration selected in
parameter 1-00 Congu-
ration Mode (Hz, Nm, or
RPM).
16-02 Reference [%]
Range: Function:
0 %* [-200 -
200 %]
View the total reference. The total reference
is the sum of digital, analog, preset, bus,
and freeze references, plus catch up and
slow down.
16-03 Status Word
Range: Function:
0* [0 - 65535 ] View the status word sent from the frequency
converter via the serial communication port in
hex code.
16-05 Main Actual Value [%]
Range: Function:
0.00 %* [-100.00 -
100.00 %]
View the 2 byte word sent with the
status word to the eldbus master
reporting the main actual value. Refer to
the VLT
®
PROFIBUS DP MCA 101
Programming Guide for further details.
16-09 Custom Readout
Range: Function:
0 CustomRea-
doutUnit*
[-999999.99 -
999999.99
CustomRea-
doutUnit]
View the user-dened readouts
as dened in
parameter 0-30 Custom Readout
Unit, parameter 0-31 Custom
Readout Min Value, and
parameter 0-32 Custom Readout
Max Value.
3.15.2 16-1* Motor Status
16-10 Power [kW]
Range: Function:
0 kW* [0 -
10000
kW]
Shows motor power in kW. The value shown
is calculated based on the actual motor
voltage and motor current. The value is
ltered, and therefore approximately 1.3 s
may pass from when an input value changes
to when the data readout values change. The
resolution of readout value on eldbus is in
10 W steps.
16-11 Power [hp]
Range: Function:
0 hp* [0 -
10000 hp]
View the motor power in hp. The value
shown is calculated based on the actual
motor voltage and motor current. The value
is ltered, and therefore approximately 1.3 ms
may pass from when an input value changes
to when the data readout values change.
16-12 Motor Voltage
Range: Function:
0 V* [0 - 6000 V] View the motor voltage, a calculated value
used for controlling the motor.
16-13 Frequency
Range: Function:
0 Hz* [0 - 6500 Hz] View the motor frequency without
resonance damping.
16-14 Motor current
Range: Function:
0 A* [0 - 10000
A]
View the motor current measured as an
average value, I
RMS
. The value is ltered, and
thus approximately 1.3 s may pass from
when an input value changes to when the
data readout values change.
16-15 Frequency [%]
Range: Function:
0 %* [-100 -
100 %]
View a 2-byte word reporting the actual motor
frequency (without resonance damping) as a
percentage (scale 0000–4000 hex) of
parameter 4-19 Max Output Frequency. Set
parameter 9-16 PCD Read Conguration index 1
to send it with the status word instead of the
MAV.
Parameter Description Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 149
3 3
