Danfoss VLT AQUA Drive FC 202 Programming Guide

4.1.24 29-** Water Application Functions
Param-
eter #
Parameter description Default value 4 set-up Change during
operation
Conversion
index
Type
29-0* Pipe Fill
29-00 Pipe Fill Enable [0] Disabled 2 set-ups FALSE - Uint8
29-01 Pipe Fill Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
29-02 Pipe Fill Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
29-03 Pipe Fill Time 0 s All set-ups TRUE -2 Uint32
29-04 Pipe Fill Rate
0.001
ProcessCtrlUnit All set-ups TRUE -3 Int32
29-05 Filled Setpoint 0 ProcessCtrlUnit All set-ups TRUE -3 Int32
29-06 No-Flow Disable Timer 0 s All set-ups TRUE -2 Uint32
29-07 Filled setpoint delay 0 s All set-ups TRUE -1 Uint16
29-1* Deragging Function
29-10 Derag Cycles ExpressionLimit 2 set-ups FALSE 0 Uint32
29-11 Derag at Start/Stop [0] O 1 set-up TRUE - Uint8
29-12 Deragging Run Time 0 s All set-ups TRUE 0 Uint16
29-13 Derag Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
29-14 Derag Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
29-15 Derag O Delay 10 s All set-ups TRUE 0 Uint16
29-2* Derag Power Tuning
29-20 Derag Power[kW] 0 kW All set-ups TRUE 1 Uint32
29-21 Derag Power[HP] 0 hp All set-ups TRUE -2 Uint32
29-22 Derag Power Factor 200% All set-ups TRUE 0 Uint16
29-23 Derag Power Delay 601 s All set-ups TRUE 0 Uint16
29-24 Low Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
29-25 Low Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
29-26 Low Speed Power [kW] ExpressionLimit All set-ups TRUE 1 Uint32
29-27 Low Speed Power [HP] ExpressionLimit All set-ups TRUE -2 Uint32
29-28 High Speed [RPM] ExpressionLimit All set-ups TRUE 67 Uint16
29-29 High Speed [Hz] ExpressionLimit All set-ups TRUE -1 Uint16
29-30 High Speed Power [kW] ExpressionLimit All set-ups TRUE 1 Uint32
29-31 High Speed Power [HP] ExpressionLimit All set-ups TRUE -2 Uint32
29-32 Derag On Ref Bandwidth 5% All set-ups TRUE 0 Uint8
29-33 Power Derag Limit 3 N/A 2 set-ups FALSE 0 Uint8
29-34 Consecutive Derag Interval ExpressionLimit All set-ups FALSE 0 Uint16
29-35 Derag at Locked Rotor [0] Disabled All set-ups TRUE - Uint8
29-4* Pre/Post Lube
29-40 Pre/Post Lube Function [0] Disabled All set-ups TRUE - Uint8
29-41 Pre Lube Time 10 s All set-ups TRUE 0 Uint16
29-42 Post Lube Time 10 s All set-ups TRUE 0 Uint16
29-5* Flow Conrmation
29-50 Validation Time ExpressionLimit All set-ups TRUE -2 Uint32
29-51 Verication Time 15 s All set-ups TRUE -2 Uint32
29-52 Signal Lost Verication Time 1 s All set-ups TRUE -2 Uint32
29-53 Flow Conrmation Mode
[0] Conrmation
Only All set-ups FALSE - Uint8
29-6* Flow Meter
29-60 Flow Meter Monitor [0] Disabled All set-ups TRUE - Uint8
29-61 Flow Meter Source [0] Analog Input 53 All set-ups TRUE - Uint8
29-62 Flow Meter Unit [0] l/s All set-ups TRUE - Uint8
29-63 Totalized Volume Unit [0] Disabled All set-ups TRUE - Uint8
29-64 Actual Volume Unit [0] Disabled All set-ups TRUE - Uint8
Parameter Lists Programming Guide
MG20OB02 Danfoss A/S © 05/2018 All rights reserved. 279
4 4
